Self-Reinforced Branch Outlet – MSS SP-97
✔ Integrally Reinforced Design – Eliminates need for external reinforcement
✔ Multiple Connection Types – Butt Weld, Socket Weld, and Threaded
✔ Customizable Angles – Available in 90° and inclined configurations
✔ Wide Material Range – Carbon Steel, Stainless Steel, Duplex, Super Duplex, Nickel Alloys
✔ Compliance with Industry Standards – MSS SP-97, ASME B31.3, B31.1, B31.4, B31.8, EN13480
✔ Cost-Effective Installation – Reduces weld deposit and labor hours
Self-Reinforced Branch Outlet – MSS SP-97 Tee
Self-Reinforced Branch Outlet – MSS SP-97 by Chero Piping is engineered to provide a fully reinforced branch connection without the need for additional welding pads or saddles. Manufactured in accordance with MSS SP-97, these fittings are designed to meet the stringent requirements of various piping codes, including ASME and EN standards.
Available in butt weld, socket weld, and threaded end connections, these branch outlets offer flexibility for different piping configurations. Their integrally reinforced design ensures structural integrity and reliability, making them suitable for high-pressure and high-temperature applications in industries such as oil & gas, petrochemical, and power generation.
Chero Piping also offers custom-designed branch outlets tailored to specific project requirements, including set-in insert branch outlets and full integral flanged options. These custom solutions are particularly beneficial on-site, as they minimize weld deposit, leading to savings in filler metal and labor hours
| Brand |
Chero Piping |
|---|---|
| Industry |
Infrastructure |
| Connection Types |
Butt Weld, Socket Weld, Threaded |
| Available Angles |
90°, Inclined Configurations |
| Size Range |
1/2" to 24" NPS |
| Pressure Ratings |
3000#, 6000#, 9000# |
| Material Options |
Carbon Steel, Stainless Steel, Duplex, Super Duplex, Nickel Alloys |
| Applicable Codes |
ASME B31.3, B31.1, B31.4, B31.8, EN13480, ASME Section VIII Division 1 |
